JUKI LIMISERVO XL-G Brushless Servo-Motor for Industrial Sewing Machines 110V Single Phase 550W (3/4 HP)

The XL-G554-10Y, part of JUKI’s LIMISERVO XC-G Series, is a compact and powerful 550W AC servo motor designed for industrial sewing machines, offering a 60% size reduction and 1.7 kg lighter weight compared to its predecessor, the XL-554. Equipped with an automatic needle positioner and paired with the XC-GMFY control box, it delivers precise speed control, enhanced stitching functions, and seamless integration with advanced operation panels like the XC-G10S. This motor combines efficiency, durability, and innovative features to meet the demands of modern sewing applications.

Motor size and weight reduction

  • Realization of the compact, lightweight motor. The motor size was reduced by approximately 60% when compared with the previous motor (XL-554). Motor weight was reduced by approximately 1.7kg.

Enhanced functionality

  • Step sequence function
    • This function enables easy programming of the desired input, output and machining operation in sequence with the stitching process. (Extensive upgrade of existing machine simple sequence mode)
    • Various operations can now be incorporated into the "stitching process", including those performed before and after operation.
  • Direct parameter No. call-up function
    • Previously it was necessary to select the respective mode to perform settings when making changes to the parameters, however, by using the G10 or G500-Y control panel, it is now possible to call up the required parameter in a single operation. It is also possible to call up parameters for each mode.

User-friendly function

  • Compute interface standard equipment
    • Settings data control including batch writing, reading and saving of settings can be performed using the setup software. (XCG_SET)
    • Step sequence creation, editing, etc. can be performed using the dedicated step sequence software. (XCG_STEP)

Multi-function, Interchangeability

  • Full functionality
    • The G series retains all the operability and multi-functionality of the XC-F series! The control box uses the same connectors as the XC-F series, enabling easy connection.
    • The settings data save function has been expanded to enable saving of settings data from 1 model to 2 models.
    • A parameter change difference display has been added. (A flashing dot ( . ) displays at the changed parameter.)
    • 2 types of function setting can now be performed with a single input.
  • Interchangeability
    • The XC-KE-01P detector, LE-FA presser foot lifter units and XC-CVS-3 variable speed pedal can all be used as is. The XL-554 motor can be used with an optional attachment bracket.
  • Control panel
    • XC-G10 and XC-G500-Y series control panels are available.
    • The existing operation panel can be attached to and removed from the XC-G10 series control panel.
    • Significant enhancements have been made to the operability of the XC-G500-Y series control panel over existing functionality (XC-E500-Y), and the settings data memory has been doubled.

Technical Specifications:

General Description

  • Product Line: LIMISERVO XC-G Series
  • Type: Induction Type AC Servo Motor with Automatic Needle Positioner
  • Manufacturer: JUKI (in collaboration with Mitsubishi Electric for LIMISERVO branding)
  • Application: Industrial Sewing Machines

Motor Specifications

  • Model: XL-G554-10Y
  • Rated Output: 550W
  • Voltage: 100–120V (Single Phase, 50/60 Hz)
  • Torque: Approximately 1.47 N·m (0.15 kg·m) (based on typical LIMISERVO G Series specs)
  • Motor Size Reduction: Approximately 60% smaller compared to the previous XL-554 model
  • Weight: Reduced by approximately 1.7 kg compared to the XL-554
  • Estimated Weight: ~6.9 kg (net), ~9.1 kg (gross)
  • Output Shaft: Taper shaft design

Control Box Compatibility

  • Control Box Model: XC-GMFY (paired with XL-G554-10Y)
  • Power Supply: 100–120V (Single Phase, 50/60 Hz)

Functions:

  • Automatic thread trimming
  • Presser foot lifting
  • Fixed-stitch stitching
  • Continuous stitching
  • Backtacking

Enhanced Features (when connected to an operation panel like XC-G10S or XC-G500Y):

  • Step sequence function: Programmable input, output, and machining operations synchronized with the stitching process
  • Simple sequence mode upgrade: Incorporates operations before and after stitching
  • Direct parameter number call-up: Allows quick parameter adjustments without mode selection

Outputs:

  • 8 solenoid drive outputs
  • 2 electromagnetic valve outputs
  • 1 small-signal output

Inputs: 14 input terminals (including variable voltage input)

Physical Characteristics

  • Compact Design: Realization of a lightweight and compact motor
  • Motor Dimensions: Specific dimensions not provided, but significantly reduced (60% smaller than XL-554)

Performance Features

  • Speed Control: Adjustable operation speed
    • Maximum speed: Up to 4000 RPM (configurable via control panel)
    • Low speed: Configurable (e.g., 1700 RPM as factory setting reference)
    • Thread trimming speed: Configurable
    • Start/end tack speed: Configurable (e.g., 1700 RPM as reference)
    • Slow start speed: Adjustable between low and high-speed settings
  • Needle Positioning: Automatic needle positioner for precise control

Additional Notes

  • Comparison to XL-554: The XL-G554-10Y is part of the XC-G Series, which offers a significant reduction in size and weight compared to the older XL-554 model, alongside enhanced functionality.
  • Safety and Installation: Requires proper installation of protective covers and position detectors (refer to the technical manual for detailed instructions).
