Consew 223R-2 Cylinder Bed Single Needle Needle Feed Industrial Sewing Machine with Table and Servo Motor​​​

No reviews yet Write a Review
Market Price: $4,219.00
$3,249.00
Save $970.00 per unit
SKU:
223R-2
Condition:
New
Shipping:
Bulk Pricing:
Quantity-Based Pricing
  • Flexible financing available through Synchrony
Need a Part? Browse our +500,000 Sewing Machine Parts Catalog!

Consew 223R-2 Cylinder Bed Single Needle Needle Feed Industrial Sewing Machine with Table and Servo Motor​​​

Market Price: $4,219.00
$3,249.00
Save $970.00 per unit

Consew 223R-2 Cylinder Bed Single Needle Needle Feed Industrial Sewing Machine with Table and Servo Motor​​​

Market Price: $4,219.00
$3,249.00
Save $970.00 per unit

Consew 223R-2 10" High Speed Cylinder Bed Single Needle Drop Feed Needle Feed Lockstitch Industrial Sewing Machine Comes With Table, Legs, and Servo Motor

Vertical Axis Rotary Hook, High Lift, Reverse Feed, Safety Clutch

Consew 223R-2 Series BrochureConsew 223R-2 Series Brochure

MACHINE APPLICATIONS:

  • For sewing medium to medium-heavy weight fabrics, leather, canvas, vinyl, synthetics and various laminated and coated materials
  • Designed for stitching tubular and curved work
  • Suitable for sewing such products as caps, cushions, boots, shoes, auto, boat and furniture upholstery, boat covers, sails, awnings, tents, light tarpaulins, camping equipment, luggage, travel ware accessories, wearing apparel, coats, etc.

MACHINE FEATURES:

  • High lift
  • Vertical axis rotary hook
  • Cylinder arm
  • Stitches per minute - 3000*
  • Reverse stitching
  • Safety clutch prevents the hook from being damaged
  • Compound feed assures even feeding of several plies or slippery material

MACHINE SPECIFICATIONS:

  • Standard or Full Function:  Standard Functions
  • Needle:  135 x 17
  • Workspace:  Standard Workspace
  • Hook:  13086
  • Feeding Mechanism: Needle Feed
  • WorkSpace:  10" (258mm)
  • Clearance Under Presser Foot:  11/32" (8.5mm)
  • Stitch Type:  301
  • Stitch Length:  5 s.p.i. (4.5mm)
  • Bed Size:  2 9/16" dia x 10 9/16" (65mm dia x 268mm)
  • Number of Needles:  1 (Single)
  • Needle Bar Stroke:  1 5/16" (33mm)
  • Bobbin: Pre-Wound G
  • Speed, Max (S.P.M.):  3000

THE ADVANTAGES OF A SERVO MOTOR:

  • Silent and use up to 90% less power than clutch motors
  • 1/3 lighter than clutch motors
  • With a flick of the switch you can reverse motor rotation
  • No parts to wear out or adjust
  • Lightweight, precise, and reliable

Thanks to the speed control feature, most users find the machine easier to use. Both beginner and advanced sewers find this feature helpful when stitching projects that require high-speed and precise stitching.
